7
Wall Mount ZV900
Installation Heights
Actual *Possible
Ceiling *Possible VENTED RECIRCULATING
Height Installation Height Installation Height
7
′ 11″
24
″ to 26″
24
″ to 26″
8 ′ 0″ 24 ″ to 27″ 24 ″ to 27″
8
′ 1″
24
″ to 28″
24
″ to 28″
8 ′ 2″ 24 ″ to 29″ 24 ″ to 29″
8
′ 3″
24
″ to 30″
24
″ to 30″
8 ′ 4″ 24 ″ to 30″ 24 ″ to 30″
8
′ 5″
24
″ to 30″
24
″ to 30″
8 ′ 6″ 24 ″ to 30″ 24 ″ to 30″
8
′ 7″
24
″ to 30″
24
″ to 30″
8 ′ 8″ 24 ″ to 30″ 24 ″ to 30″
8
′ 9″
24
″ to 30″
24
″ to 30″
8 ′ 10″ 24 ″ to 30″ 25 ″ to 30″
8
′ 11″
24
″ to 30″
26
″ to 30″
9 ′ 0″ 25 ″ to 30″ 24 ″ to 30″
9
′ 1″
26
″ to 30″
24
″ to 30″
9 ′ 2″ 27 ″ to 30″ 24 ″ to 30″
9
′ 3″
28
″ to 30″
24
″ to 30″
9 ′ 4″ 29 ″ to 30″ 24 ″ to 30″
9
′ 5″
30
″
25
″ to 30″
9 ′ 6″ 24 ″ to 30″ 24 ″ to 30″
9
′ 7″
24
″ to 30″
24
″ to 30″
9 ′ 8″ 24 ″ to 30″ 24 ″ to 30″
9
′ 9″
24
″ to 30″
24
″ to 30″
9 ′ 10″ 24 ″ to 30″ 24 ″ to 30″
9
′ 11″
24
″ to 30″
24
″ to 30″
10 ′ 24 ″ to 30″ 24 ″ to 30″
10
′ 1″
24
″ to 30″
24
″ to 30″
10 ′ 2″ 25 ″ to 30″ 24 ″ to 30″
10
′ 3″
26
″ to 30″
25
″ to 30″
10 ′ 4″ 27 ″ to 30″ 26 ″ to 30″
10
′ 5″
28
″ to 30″
27
″ to 30″
*Based on 36
″
countertop height.
A
C
CESSORY
ZX90010
SUPPLIED
DETERMINE INSTALLATION HEIGHT
• Telescopic duct covers are provided to conceal
the ductwork running to the ceiling.
• This hood can be installed for recirculating
operation. No kits required.
The vent hood must be installed 24 ″ min. and
30 ″ max. above the cooking surface. The hood
installation height, from the cooking surface to the
bottom of the hood, depends upon ceiling height.
Installation Preparation
24” Min.
30” Max.
36” Min.
A
C
CESSORY
ZX90010
NOTE: Measure
installation height
from the cooking
surface to the outer
glass portion of the
hood.
ACCESSORIES:
• Order ZX90010 accessory for ZV900 wall mount
hood to reach ceiling heights between 9 ′ 6 ″ and
10 ′ 5 ″ . This accessory contains one 40 ″ long duct
cover.
