G0445/G0582/G9962Z/9962ZX Wide Belt Sander -59-
Feed, Drum, and Pressure Roller Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
4101 P05824101 PISTON SLIDE RAIL (G0582) 4205 PSS07 SETSCREW 1/4-20 X 1/2
4102 P05824102 PISTON BRACKET (G0582) 4301 P9962Z4301 PISTON ROD
4103 P9962Z4103 COMPRESSION SPRING (G9962Z/G9962ZX/G0445)
4104 P9962Z4104 ROD 10 X 35 (G0582) 4302 P9962Z4302 BRACKET
4105 PSS07 SET SCREW 1/4-20 X 1/2 (G0582) (G9962Z/G9962ZX/G0445)
4106 PB11 HEX BOLT 5/16-18 X 1-1/2 (G0582) 4303 PRP55M ROLL PIN 3 x 27
4107 PN02 HEX NUT 5/16-18 4304 P9962Z4304 SLIDERAIL (G9962Z/G9962ZX)
4108 PB12 HEX BOLT 5/16-18 X 1-1/4 4401 P04454301 BRACKET (G0445)
4109 PLW01 LOCK WASHER 5/16 4402 P04454302 DEFLECTOR (G0445)
4201 P9962Z4201 PISTON ROLLER SHAFT 4403 P04454303 BRACKET (G0445)
4202 P9962Z4202 PISTON ROLLER 4404 P04454304 DEFLECTOR (G0445)
4203 P6001 BEARING 6001ZZ 4405 P04454305 BRACKET (G0445)
4204 P9962Z4204 SHAFT BEARING COLLAR
