G0445/G0582/G9962Z/9962ZX Wide Belt Sander -57-
Conveyor System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
3101 P9962Z3101 CONVEYOR TABLE 3123-2 P9962ZX3123-2 FAN COVER
3102 P9962Z3102 CONVEYOR BELT (G9962ZX/G0582/G0445)
3103 P9962Z3103 GEARBOX FIX PLATE 3124 PLW06M LOCK WASHER 10MM
3104 P9962Z3104 CUSHION 3126 P9962Z3126 TIMING BELT
3105 PW02 FLAT WASHER 3/8 3127 PB32M HEX BOLT M10-1.5 X 25
3106 PB18 HEX BOLT 3/8-16 X 1 3128 P9962Z3128 VARIABLE SPEED BASE PLATE
3107 P9962Z3107 OUTFEED ROLLER 3129 P9962Z3129 VARIABLE SPEED COVER
3108 P9962Z3108 BEARING UCF205 3130 PB09M HEX BOLT M8-1.25 X 20
3109 P9962Z3109 REDUCER 3131 P9962Z3131 INFEED ROLLER BRACKET
3110 P9962Z3110 PLUG 3132 PSB16 CAP SCREW 3/8-16 X 3/4
3111 P9962Z3111 PLUG 3133 P9962Z3133 INFEED ROLLER BRACKET
3112 P9962Z3112 BEARING UCF205 3135 P9962Z3135 POSITIONING WHEEL
3113 PLW04 LOCK WASHER 3/8 3136 PSB70 CAP SCREW 5/16-18 X 2
3114 PB24 HEX BOLT 3/8-16 X 1-1/4 3137 PLW01 LOCK WASHER 5/16
3115 P9962Z3115 BEARING CAP 3138 PN02 HEX NUT 5/16-18
3116 P9962Z3116 DRIVE PULLEY 3140 P9962Z3140 FRONT BRAKE COVER
3117 PB16 HEX BOLT 3/8-16 X 1-1/2 3141 PS04 PHLP HD SCR 1/4-20 X 1/2
3118 P9962Z3118 DRIVE PULLEY 3142 P9962Z3142 LIMIT SWITCH
3119 PK66M KEY 7 X 7 X 55 3143 PS31 PHLP HD SCR #10-24 X 1-3/4
3120 PB07M HEX BOLT M8-1.25 X 25 3144 PB74 HEX BOLT 1/2-13 X 3
3121 PLW04M LOCK WASHER 8MM 3201 P9962Z3201 INFEED ROLLER SHAFT
3123 P9962Z3123 1 HP MOTOR 1-PH (G9962Z) 3202 P9962Z3202 INFEED ROLLER
3123-1 P9962Z3123-1 MOTOR FAN COVER (G9962Z) 3203 P6206 BEARING 6206ZZ
3123-2 P9962Z3123-2 MOTOR FAN (G9962Z) 3204 PR15M EXT RETAINING RING 30MM
3123 P9962ZX3123 1 HP MOTOR 3-PH 3205 P9962Z3205 ELEVATION LIMITER
(G9962ZX/G0582/G0445) 3206 PSB32 CAP SCREW 1/4-20 X 1-1/4
3123-1 P9962ZX3123-1 MOTOR FAN
(G9962ZX/G0582/G0445)
