Grandstream Networks, Inc.

GXP–2020 Users Manual

Page 24 of 33

Firmware 1.1.4.3

Last Updated: 05/2007

Table 10: Device Configuration - Status Definitions

Hardware Revision

Hardware version number: Main Board, Interface Board

MAC Address

The device ID, in HEXADECIMAL format.

IP Address

This field shows IP address of GXP-2020

Product Model

This field contains the product model information.

Software Version

Program: This is the main software (firmware) release number, always used to

identify the software (firmware) system of the phone.

Boot: Booting code version number

System Up Time

This field shows system up time since the last reboot.

Registered

Indicates whether accounts are registered to the related SIP server(s). GXP-2020 can
support four unique SIP profiles.

PPPoE Link Up

Inidicates whether the PPPoE connection is enabled (connected to a modem).

Table 11: Device Configuration – Basic Settings Definitions

End User
Password

This contains the password to access the Web Configuration Menu. This field is
case sensitive with a maximum length of 25 characters.

IP Address

There GXP-2020 operates in two modes:

1. DHCP mode: all the field values for the Static IP mode are not used (even

though they are still saved in the Flash memory.) The GXP-2020 acquires
its IP address from the first DHCP server it discovers on its LAN. The
DHCP option is reserved for NAT router mode. To use the PPPoE feature,
set the PPPoE account settings. The GXP-2020 establishes a PPPoE
session if any of the PPPoE fields are set.

2. Static IP mode: configure all of the following fields: IP address, Subnet

Mask, Default Router IP address, DNS Server 1 (primary), DNS Server 2
(secondary). These fields are set to zero by default.

Multi purpose key 1-7

These options are used to assign a function to the corresponding multi purpose key.
Options available are: “Speed dial”, “Asterisk BLF”, “Presence Watcher” and
“Eventlist BLF”.
Each function is connected to one of the 6 accounts and has a target user ID.

Time Zone

This parameter controls the date/time display according to the specified time zone.

Daylight Savings Time

This parameter controls time displayed in daylight savings time or not. If set to
“Yes”, then the displayed time will be 1 hour ahead of normal time.

Time Display Format

LCD time display in 12 hour or 24 hour format

Date Display Format

Choose one of the following formats:

• Year-Month-Day

• Month-Day-Year

• Day-Month-Year
