Switch Material: Copper alloys
Momentary (N.O./N.C./Com) Single Pole Double Throw
/ AC
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7mm
Max. Rating : 3A 125/250 V
Materials:ABS
Switch Ratings : 1.5A, 250V
or 1A, 125~250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Cable Length : 4 Meters
Rectangular faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
S
GIANNI INDUSTRIES, INC.
Micro Switch
Copyright © 2010 Gianni Industries, Inc. All rights reserved.
DM-CA-PBT-Switch Ver. E Published on 2011.05.10
SWH-10405
Unit: mm
22.5
22.5
2.5
5.0
Ш 20.0
Ш 8.5
Ш 4.5
Ш 15.0
42.0
SWH-10400 SWH-10500
26
35 55
Ф10.5
Ф5.1
ФM18
Unit:mm
Ф M18XP1.0mm
3
34
25
Ф M18XP1.0mm
3
3
3
34
25
5535
26
Ф10.5
Ф 5.1
Ф M18
Unit:mm
3
34
25
Ф M18XP1.0mm
3
23
M18x1.0P
3
2
4
2
23
3
2
4
2
SWH-10405CB SWH-10505CB
SWH-10405CB-42 SWH-10505CB-42
Materials:ABS
Switch Ratings : 1.5A, 250V
or 1A, 125~250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Cable Length : 4 Meters
Oval-shaped faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
S
Position bolt
Switch Ratings : 5A/250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Rectangular stainless
steel faceplate
Faceplate Dimensions:
55(H)x26(W)x3(D)mm
S
Position bolt
Switch Ratings : 5A/250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Oval-shaped stainless
steel faceplate
Faceplate Dimensions:
55(H)x26(W)x3(D)mm
S
Position bolt
Switch Ratings : 5A/250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Rectangular stainless
steel faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
Narrow Faceplate
S
Position bolt
Switch Ratings : 5A/250VAC
ingle pole double throw (SPDT)
(COM,N/C,N/O)
Dimension: M18XP1.0mm
Cable Length : 4 Meters
Oval-shaped stainless
steel faceplate
Faceplate Dimensions:
42(H)x23(W)x3(D)mm
Narrow Faceplate
S
Copper
Stainless
