Gianni Industries SWH-040 - Manual (Page 2)

17.5
14.0
Material: Stainless steel
Momentary (N.O.) Single Pole Single Throw
Max. Rating : 5mA/12VDC
Contact resistance: 1kΩ Max.(initial)
Operating life(5mA/5VDC) : Over 100,000 times
Operating travel: 1.75mm
MSW-1901-EXIT
MSW-2501-EXIT
MSW-1901-EXIT
MSW-2501-EXIT
MSW-1902-EXIT
MSW-2502-EXIT
MSW-1902-EXIT
MSW-2502-EXIT
16.0
14.0
8.0
22
1.0
0.5mm thickness
M19 x P1.0 mm
34mm
2mm
22mm
2.0
2.7mm
Free Position
Operation Position
Material: Stainless steel
Momentary (N.O./N.C.) Double Pole Double Throw
Max. Rating : 5A/125/250 VAC
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Cables included
M19 x P1.0mm
S-SI-PBT-4-GEM
SWH-CN020
27mm
3mm
22mm
2.0
2mm
Free Position
Operation Position
M19 x P0.75mm
Material : Copper alloy
3A/125V AC, 6A/24V DC
Momentary(N.O.) Single Pole Single Throw
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.0 mm
Max. Rating :
SWH-1922
SWH-1925
Materials: Stainless steel
Momentary(N.O./N.C.) Double Pole Double Throw
Max. Rating : 5A/125/250 VAC
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7 mm
Cables included
32mm
28mm
22mm
(25mm)
2.0
M19 x P1.0mm
2.7mm
Free Position
Operation Position
Operating travel: 2.7mm
GIANNI INDUSTRIES, INC.
Micro Switch
Copyright © 2010 Gianni Industries, Inc. All rights reserved.
DM-CA-PBT-Switch Ver. E Published on 2011.05.10 No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
