Gianni Industries SWH-040 - Manual (Page 3)

Free Position
Free Position
Operation Position
Operation Position
45.0
23.0
M22 x P1.5mm
0.6mm
thickness
2.0
5
35.0 29.9
Operating travel:
2.7mm
Operating travel:
2.7mm
Material: Zinc alloy
Momentary (N/O,N/C) Double Pole Double Throw
Contact resistance: 50mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7mm
Max. Ratings : 5A@125/250 Vac
Material: PVC
/ AC
Momentary (N/O,N/C) Double Pole Double Throw
Contact resistance: 50mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7mm
Max. Rating : 5A 125/250 V
(SWH-160-GE)
SWH-160-RE SWH-160-GE
SWH-190-RE SWH-190-GE
M22 x P1.5mm
0.6mm
thickness
20.5 29.9
36
23
5
GIANNI INDUSTRIES, INC.
Micro Switch
Copyright © 2010 Gianni Industries, Inc. All rights reserved.
DM-CA-PBT-Switch Ver. E Published on 2011.05.10 No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
