Motor assembly – Grizzly G0588/G0591 User Manual
Page 74
-66-
G0588/G0591 12" Sliding Table Saws
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
22
PN03M
HEX NUT M8-1.25
216-3
PC045A
R CAPACITR 45M 250 V (G0591)
24
PB34M
HEX BOLT M10-1.5 X 60
216-4
PC600
S CAPACITR 600M 125V (G0591)
25
PN02M
HEX NUT M10-1.5
216-5
P0591216-5
R CAPACITOR COVER (G0591)
91
PW04M
FLAT WASHER 10MM
216-6
P0591216-6
S CAPACITOR COVER (G0591)
101
P0588101
NYLON SCREW M12-1.75 X 12
216-7
P0588216-7
WIRING CONNECT BOX (G0588)
118
PLN04M
LOCK NUT M8-1.25
216-7
P0591216-7
WIRING CONNECT BOX (G0591)
164
P0588164
TW-NUT
217
PB74M
HEX BOLT M10-1.5 X 20
193
P0588193
DUST COVER
218
PLW06M
LOCK WASHER 10MM
194
PSB11M
CAP SCREW M8-1.25 X 16
219
P0588219
SPANNER NUT M25-1.5
195
PFH11M
FLAT HD SCR M8-1.25 X 15
220
P0588220
MOTOR PLATE
196
P0588196
HEX NUT M16-2 (LH)
221
PR09M
EXT RETAINING RING 20MM
197
P0588197
ARBOR FLANGE
222
P0588222
ROTATE HOUSING
198
PRP74M
ROLL PIN 4 X 8
223
PRP08M
ROLL PIN 6 X 30
200
P0588200
BLADE ARBOR
224
P0588224
BLADE GUARD
201
P6004
BALL BEARING 6004ZZ
227
P0588227
ADJUST HANDLE M8-1.25 X 30
203
PSB46M
CAP SCREW M4-.7 X 40
228
P0588228
RIVING KNIFE
204
PN04M
HEX NUT M4-.7
229
P0588229
COVER LOCK BLOCK
205
P0588205
LIMIT SWITCH
269
P0588269
SWTCH CRD 1.0 X 2C X 7500MM
206
P0588206
V-BELT 3V-256
270
P0588270
POWER CRD 1.5 X 4C X 7000MM
207
P0588207
MOTOR PULLEY
271
P0588271
MOTOR CRD 1.5 X 4C X 7000MM
208
PR71M
EXT RETAINING RING 60MM
272
P0588272
SWTCH CRD 1.0 X 4C X 7000MM
209
PSS16M
SET SCREW M8-1.25 X 10
280
P0588280
WAVE WASHER 60MM
210
PSB11M
CAP SCREW M8-1.25 X 16
281
PAW02M
HEX WRENCH 2MM
211
P0588211
RIVING KNIFE HOLDER
282
PAW03M
HEX WRENCH 3MM
212
P0588212
RIVING BRACKET
283
PAW06M
HEX WRENCH 6MM
213
PCB25M
CARRIAGE BOLT M12-1.75 X 35
284
P0588284
T-KEY WRENCH 4MM
214
PSS01M
SET SCREW M6-1 X 10
285
P0588285
T-KEY WRENCH 5MM
215
PK42M
KEY 6 X 6 X 30
286
P0588286
T-KEY WRENCH 6MM
216
P0588216
MOTOR 5HP-1PH (G0588)
287
P0588287
WRENCH 13MM
216
P0591216
MOTOR 7.5HP-3PH (G0591)
288
P0588288
WRENCH 19MM
216-1
P0588216-1
MOTOR FAN (G0588)
289
PWR1012
WRENCH 10 X 12
216-1
P0591216-1
MOTOR FAN (G0591)
290
PWR1417
WRENCH 14 X 17
216-2
P0588216-2
MOTOR FAN COVER (G0588)
291
P0588291
WRENCH 22 X 24
216-2
P0591216-2
MOTOR FAN COVER (G0591)
305
PN09M
HEX NUT M12-1.75
Motor Assembly
