G0588/G0591 12" Sliding Table Saws
-19-
Crate 2 .......................................................... Qty
S. Sliding Table (Not Shown) ............................ 1
Hardware and Tools
•
Hex Bolt M10-1.5 x 45 ............................... 1
•
Hex Nuts M6-1.0 ........................................ 3
•
Cap Screws M8-1.25 x 30 .......................... 4
•
Cap Screws M6-1.0 x 20 ............................ 5
•
Set Screws M8-1.25 x 20 ........................... 2
•
Flat Washer 10mm ..................................... 3
•
Flat Washers 8mm ..................................... 5
•
Flat Washers 6mm ..................................... 3
•
Lock Washers 8mm ................................... 4
•
Lock Washer 10mm ................................... 1
•
Flip Stops ................................................... 2
•
Push Handle M14-2 x 16 w/T-Nut .............. 1
•
Lock Knobs M10-1.5 .................................. 2
•
T-Hex Wrenches 6, 5, 4mm ..................1 Ea
•
Hex Wrenches 6, 3, 2mm .....................1 Ea
•
Open End Wrenches
10/12, 14/17, 22/24mm .........................1 Ea
•
Combo Wrenches 13, 19mm ................1 Ea
•
Push Stick .................................................. 1
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
Q. Edge Shoe .................................................. 1
R. Hold Down .................................................. 1
N. Blade Guard/Dust Hood ............................ 1
O. Adjustable Handle M8-1.25 x 28 ................ 1
P. Riving Knife ................................................ 1
Figure 14. Blade guard components.
P
N
O
Figure 15. Included accessories.
Q
R
J. Crosscut Table ........................................... 1
K. Crosscut Table Lock Plate ......................... 1
L. Adjustable Handles M10-1.5 ...................... 2
M. Crosscut Aluminium Fence ........................ 1
Figure 13. Crosscut table components.
L
J
K
M
