-62-
G0588/G0591 12" Sliding Table Saws
REF PART # DESCRIPTION REF PART # DESCRIPTION
28 PN13M HEX NUT M16-2 144 P0588144 ROLLER
104 PSB117M BUTTON HD CAP SCR M5-.8 X 8 145 PB33M HEX BOLT M12-1.75 X 50
132A P0588132A RIP FENCE BASE 146 PSB14M CAP SCREW M8-1.25 X 20
133 PR06M EXT. RETAINING RING 16MM 147 PB28M HEX BOLT M8-1.25 X 60
134 P0588134 WARNING LABEL PLATE 148 P0588148 RIP FENCE PLATE
135 P0588135 RIVET 149 P0588149 LOCK BLOCK (LONG)
136 PEC07M E-CLIP 7MM 150 P0588150 LOCK BLOCK (SHORT)
137 P0588137 HANDLE 151 P0588151 ECCENTRIC SHAFT
139 P0588139 COMPRESSION SPRING 152 P0588152 HOLD PLATE
140 P0588140 KNOB M14-1.75 153A P0588153A ECCENTRIC
142 P0588142 HANDLE 305 PN09M HEX NUT M12-1.75
143 P0588143 ECCENTRIC 306 PTLW12M EXT TOOTH WASHER 12MM
Rip Fence
