Generac PRIMEPACT 50 04164-3 User Manual
Page 53
51
ITEM PART
NO.
QTY.
DESCRIPTION
1
0A6532
1
MANIFOLD,
INTAKE
2
091039
1
GASKET,
MANIFOLD/HEAD
3
051753
1
HHCS-M6-1.0 X 40MM
4
0E7585
1
SPARK PLUG, CHAMP
5
089228
1
GASKET,
CARB/MANIFOLD
6
0A7336B
1
CARBURETOR, GN 410 L/P
0A6562
1
CARBURETOR, GN410 GAS
7
090970
1
GASKET, CARB/AIR FILTER
8
0A7660
1
ASSY, AIR CLEANER/VALVE
0A7660A
1
ASSY, AIR CLEANER/VALVE W/EVAP (02010-3 & 05754 ONLY)
9
056893
3
CRIMPTITE #10-24 X 1/2”
10
0A6566
1
DETENT
11
0A6780
1
SPRING, A/L BELLCRANK-CARB.
12
096290
2
STUD, CARB. MOUNT 90 LG.
13
073111
1
FILTER, AIR
14
15
0A6563
1
COVER, AIR FILTER
16
0C3633
2
KNOB, AIR CLEANER
17
0A6581A
1
BREATHER, TUBE
18
0C2332
1
DECAL, AIRBOX QP55
19
092164
1
ASSEMBLY, GOV. SPRING ADI BRACKET
20
082025
1
NUT HEX LOCK M5-0.8 NYLON
21
0A7029
1
NYLON WASHER, .31” X .26” X .13”
22
0A6913
1
ROD, LINKAGE GOV. LEVER-BELLCRANK
23
091161
1
BOLT, SHOULDER, M6-1.0 X 15MM
24
049813
2
NUT, M6-1.0
25
092586
2
WASHER, FELT
26
083512
2
TAPTITE-M8-1.25 X 16MM
27
0A6778
1
SPRING, A/L GOV. LEVER-BELLCRANK
28
0A6785
1
ROD, LINKAGE BELLCRANK-CARB.
29
0A6753
1
BELLCRANK, GOV. RODS
30
0A8222
1
SPRING, GOVERNOR
31
086681
1
NUT, GOVERNOR LEVER
32
020753
1
HHCS-M6-1.0 X 60MM
33
022473
2
M6 FLAT WASHER
34
022097
4
M6 LOCK WASHER
35
0A6582
1
TUBE, WINTER INLET
36
0A6503
1
GROMMET 1/16”-1-1/2”
37
0A6569
1
GROMMET, AIR IN/OUT
38
0A7660
1
VALVE, WINTER/SUMMER
39
0A6568
1
GROMMET, WINTER/SUMMER VALVE
40
0A6567
1
SPRING, DETENT
41
091916
1
LEVER, GOVERNOR ARM
42
083532
1
BOLT, HEX HD. WASHER/LOCK WASHER-M6-1.0 X 30MM
43
072683A
1
PLUG, 1/8 NPTF (02010-3 ONLY)
028414A
1
BARBED STRAIGHT 1/8 NPT X 1/4 (05754-0 ONLY)
44
0A6239
1
ASSEMBLY, CHOKE SOLENOID (02010-3 & 05754 ONLY)
45
0A6584
1
LINKAGE, CHOKE (02010-3 & 05754 ONLY)
46
036544
1
PIN, COTTER 3/32” X .5” (02010-3 & 05754 ONLY)
47
089473
1
ASSEMBLY, CHOKE HEATER (02010-3 & 05754 ONLY)
48
0A7094
2
PPHMS #4-40 X .25” (02010-3 & 05754 ONLY)
Section 6 — Exploded Views and Parts Lists
Recreational Vehicle Generator
Engine Accessories – Drawing No. 0F1135-E
