41
ITEM PART
NO. QTY. DESCRIPTION
1
0C2368
1
BASE, MOUNTING
2
053407
1
GROUND CABLE
3
046911
4
MOUNT, (RUBBER)
4
025017
6
CAPSCREW, HEX HD.-3/8"-16 X 1/2"
5
022237
6
LOCK WASHER-3/8"
6
022129
9
LOCK WASHER-M8
7
0A6479
1
SKID, RUBBER MOUNT
8
077603
2
SAFETY BOLT 5/16"-18 X 3 1/2"
9
022259
2
NUT, HEX-5/16"-18
10
052858
6
NUT, FLANGED LOCK-M8-1.25
11
051730
2
CAPSCR. HEX HD.-M8-1.25 X 60MM
12
029459
2
SPRING, BELT TENSION
13
075215
2
WASHER, SPRING CNTR.
14
073146
4
SLIDE (NYLON)
15
075209
2
SUPPORT, NYLON SLIDE
16
0A8341
1
MANIFOLD, EXHAUST
17
090239
1
GASKET, EXHAUST MANIFOLD
18
040976
2
SOCKET HD. CAPSCR.,-M8-1.25 X 20
LG.
19
0A6858
1
GASKET, COLLECTOR PAN
20
0A8614
1
SKID, RUBBER MOUNT
21
075224B
1
PULLEY, ENGINE
22
073106B
1
PULLEY, ALT.
23
075216
1
BELT (POLY V 4L)-40"
24
049451
1
WASHER, PULLEY RETAINER
25
042633
1
CAPSCR., SOCKET HD. 3/8"-24 X 1"
(GRADE 5)
26
039253
3
CAPSCR., HEX HD.-M8-1.25 X 20
27
0A8250
1
CAPSCR., HEX HD.-3/8"-24 X 2"
28
056893
5
CRIMPTITE-#10-24 X 1/2"
29
0A8615
1
BRACKET-FUEL PUMP
30
0C1320
1
HOUSING, BLOWER
31
063036
3
CRIMTITE-#8-18 X 1/4”
32
0A8694
1
SCREEN, SLIDE PAN
33
0A8726
1
GASKET, BLOWER / PAN
34
075242
4
SPRING, GENERATOR SET MT
ITEM PART
NO. QTY. DESCRIPTION
35
0C4006
1
CABLE, BATTERY
36
0A4456
2
3/8" SPECIAL LOCK WASHER
37
090475
1
FUEL PUMP
38
087769
1
FUEL FILTER
39
0A7695
1
FITTING-1/8" PIPE TO 1/4" TUBE
40
0A6922
1
FUEL TUBE, METAL
41
079246
2
CAPSCR., HEX HD.-M6-1.0 X 16
42
022145
5
FLAT WASHER-M8-5/16"
43
023897
3
FLAT WASHER-#10
44
0A8010A
1
GASKET, BLOWER HSNG
45
077643
1
EXHAUST PIPE GASKET
46
075237
4
WASHER, SPRING RETAINER
47
0D1741A
1
BOOT, STARTER CONTACTOR
48
090859
1
EXHAUST COVER PLATE
49
0F9176
6 IN. HOSE, FUEL
50
0A8594
1
PAN, SLIDE
51
0A1658
2
SPECIAL LOCK WASHER, ¼”
52
023152
2
CAPSCR., HEX HD.-3/8"-16 X 3/4"
53
0A8475
3
SPECIAL LOCK WASHER, M5
54
045756
2
SCREW, TAPTITE-M6-1.0 X 10 LG.
55
022131
1
FLAT WASHER-M10
56
048031C
2
CLAMP, HOSE
57
081105
2
NUT, FLANGE-5/16"-18 (SPECIAL)
58
066849
5
SCREW, TAPTITE M5-0.8 X 16 LG.
59
0D1227
1
STARTER CONTACTOR
60
0A8010
1
GASKET, BLOWER HSNG
61
0C2824
7
HHS #10-32 X 9/16” LG, TAP-R
62
0742600131
1
STARTER CABLE
63
024114
2
HEX NUT-5/16”-24
64
0D1741
2
BOOT, STARTER CONTACTOR
65
022152
2
LOCK WASHER-M4
66
022158
2
HEX NUT-#10-32
67
0A8531
1
PLATE, BLOWER SIDE
68
0A8407
1
GASKET, BLOWER SIDE
69
022473
1
FLAT WASHER ¼”
70
0A2110
2
SCREW, SWAGE 1/4–28 X 1/2”
Section 6 — Exploded Views and Parts Lists
Recreational Vehicle Generator
Base and Pulleys (Model 05754-0) – Drawing No. 0D1759-E
