GE Monogram ZX2L SS User Manual

Page 9

Step

Test for
Leaks

WARNING

TEST FOR LEAKS

A complete gas tightness check must be
performed at the installation site. DO NOT
USE A FLAME TO CHECK FOR GAS
LEAKS.

• Do not use the burner until all connections

have been leak tested.

• Repeat leak test after each LP tank change or

gas re-connect.

• Check to be sure the main valve on the LP

tank or the shut-off valve is in the “OFF”
position.

• Make a soap solution of one part liquid

detergent and one part water.

The valve panel must be removed to check
the valves and fittings.
• All control valves should be in the “OFF”

position.

• Remove the knobs.
• Remove the 4 screws holding the valve panel

to the burner.

• Pull the panel outwards and unplug the wire

from the back of the rotary igniter.

TO TEST:
• Apply the soap solution around all

connections, valve and tubing.

• Turn the gas supply on.
• Check all connections from the supply line

or LP tank up to and including the manifold
pipe assembly.

• If a leak is detected, turn gas supply off and

tighten fittings. Turn the gas on and check
again.

• To re-install the valve panel, re-connect the

igniter wire and secure the panel with
original screws.

TO MATCH LIGHT:
• Remove the burner grate.
• Strike match and hold adjacent to burner

port.

• Push and turn the control knob to “LITE”.
• Rotate the control knob to desired setting.
• Replace grate.
ALWAYS TURN GAS SUPPLY OFF AT THE
SHUT-OFF VALVE OR LP TANK WHEN
NOT IN USE.

Step

Lighting
the Burner

WARNING

Do not attempt to light

the burner if the odor of gas is present.

CAUTION: Keep hands and face as far away
from the burner as possible when lighting.
• Remove burner cover.
• Turn all knobs to “OFF” position.
• Turn gas supply on at the LP tank or shut-off

valve.

NOTE: When lighting the burner for the first
time or after a LP tank change, up to 20
seconds may be required to purge air from
the lines.
• Push and turn control knob counter-clockwise

to “LITE” position, turn the small igniter
knob next to the burner knob clockwise.

NOTE: The spark will produce a snapping
sound. This is normal.
• If the burner does not light within 4 seconds,

turn knobs to “OFF and wait 5 minutes for
the gas to dissipate before trying again.

• If the burner does not light after several

attempts, the burner can be lit with a match.

Installation

Dual Burner Outdoor Cooktop
