Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
51 P9249051 BRACKET AXLE 86 P9249086 HINGE
52 P9249052 IDLER PULLEY SHAFT 87 PRP49M ROLL PIN 5 X 25
53 P9249053 IDLER BRACKET 88 P9249088 PLUG
54 PB107M HEX BOLT M5-.8 X 12 89 P9249089 PLUG BASE
55 P9249055 BRACKET CAP SMALL 90 P9249090 HEADSTOCK CASTING
56 P9249056 BRACKET CAP LARGE 91 PSB84M CAP SCREW M10-1.5 X 35
57 P9249057 SPANNER NUT M10-1.0 92 PSB72M CAP SCREW M10-1.5 X 30
58 P6005 BALL BEARING 6005ZZ 93 PSB13M CAP SCREW M8-1.25 X 30
59 P9249059 IDLER PULLEY 94 P9249094 SIGHT GLASS
60 P9249002 BALL OILER 95 P7211 BEARING D-7211
61 PVB38 V-BELT B-38 5L380 96 P9249096 SPINDLE
62 P9249062 SPECIAL LOCK NUT 97 P9249097 MOTOR MOUNT
63 P9249063 SPECIAL BOLT M5-.8 X 20 98 PSB13M CAP SCREW M8-1.25 X 30
64 P9249064 ADJUSTABLE NUT M5-.8 99 P9249099 MOTOR BASE PLATE
65 P9249065 SPECIAL BOLT M5-.8 X 16 100 PN09M HEX NUT M12-1.75
66 P9249066 ECCENTRIC ARM 101 PW06M FLAT WASHER 12MM
67 PB95M HEX BOLT M5-.8 X 16 102 PB43M HEX BOLT M12-1.75 X 75
68 PSS14M SET SCREW M8-1.25 X 12 103 PSB14M CAP SCREW M8-1.25 X 20
69 PRP28M ROLL PIN 5 X 40 104 P9249104 SPINDLE FRONT COVER
70 P9249070 SHAFT 105 P9249105 PAPER WASHER 10MM
71 PRP94M ROLL PIN 5 X 14 106 P9249106 KEY 8 X 14
72 P9249072 HANDLE 107 PK144M KEY 6 X 6 X 16
73 P9249073 KNOB M10-1.5 X 50 108 P9249108 BACK GEAR BUSHING
74 P9249074 HANDLE HUB 109 P9249109 BACK GEAR SHAFT
75 P9249075 MOTOR 2HP 220V 60HZ 1PH 110 P9249110 BACK GEAR 24/58T
75-1 PC200A S CAPACITOR 200M 250V 1-3/8 X 2-3/4 111 P9249111 BACK GEAR BRACKET
75-2 PC20A R CAPACITOR 20M 400V 1-5/8 X 2-3/4 112 P9249112 BACK GEAR MOUNT
75-3 P9249075-3 CAPACITOR COVER 113 PSB04M CAP SCREW M6-1 X 10
75-4 P9249075-4 MOTOR FAN 114 P9249114 LOCKING PIN
75-5 P9249075-5 MOTOR FAN COVER 115 P9249115 COMPRESSION SPRING .8 X 5 X 1.5
75-6 P9249075-6 MOTOR WIRING JUNCTION BOX 116 P9249116 HANDLE
76 PLW04M LOCK WASHER 8MM 117 P9249117 KNOB
77 PB07M HEX BOLT M8-1.25 X 25 118 PN01M HEX NUT M6-1
78 PK142M KEY 6 X 6 X 32 119 P9249119 FIGURED FLAT NUT M8-1.25
79 PSS06M SET SCREW M8-1.25 X 16 120 PRP02M ROLL PIN 3 X 16
80 P9249080 MOTOR PULLEY 121 P9249121 HELICAL GEAR
81 P9249081 V-BELT B-813 122 P9249122 COMPRESSION SPRING 1 X 5 X 1.5
83 P9249083 GEARBOX COVER 123 P9249123 LOCKING PIN
84 PB20M HEX BOLT M8-1.25 X 35 124 P9249124 SPINDLE PULLEY
85 PSB14M CAP SCREW M8-1.25 X 20 125 PSS01M SET SCREW M6-1 X 10
