Magnum14E Media Converters Installation and User Guide (10/02)
26
www GarrettCom com
.
.
Fiber
Port
Module
Speed,
Std.
Mode
Std. km
fdx
(hdx)
Wave-
length
nm
Cable
Size
µm
X’mitr
Output
P
T ,
dB
R’cvr
Sens.
P
R ,
dB
Worst
OPB,
dB
Worst*
distance
Km, fdx
typical
OPB,
dB
typical*
distance
Km, fdx
14E-
MST, MSC
100Mb
FX
Multi-
mode
2
(0.4)
1300 62.5/125
50/125
-20
-23.5
-31
-31
9.0
5.5
2.5
2.0
14
12
5
4
14E-SSC
100Mb
FX
Single-
mode
25
(0.4)
1300
9/125
-15
-31
14
28
17.5
35
14E-MTRJ
100Mb
FX
Multi-
mode
2
(0.4)
1300
62.5/125
50/125
-20
-23.5
-31
-31
9.0
5.5
2.5
2.0
14
12
5
4
14E-SSCL
Long Reach
100Mb
FX
Single-
mode
40
(0.4)
1300
9/125
-5
-34
27
54
32.5
65
* Note: The use of either multi-mode or single-mode fiber to operate at 100Mbps speed over
long distances (i.e., over approx. 400 meters) can be achieved
only
if the following factors are
both applied:
