G7945/G7946 Radial Drill Press
-43-
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P7946001 BASE V2.04.03 74 P7946074 WORM GEAR
3 PB31M HEX BOLT M10-1.5 X 40 80 P7946080 COLUMN RING
4 P7946004 LONG COLUMN W/COLUMN HOLDER V3.02.99 83 P7946083 ROUND TABLE
4A-1 P7946004A-1 LONG RACK 84 P7946084 COLUMN SUPPORT ARM
7 P7946007 GEARED TABLE BRACKET V2.03.99 84A P7946084A TABLE SUPPORT ARM
7-1 P7946007-1 COMPLETE TBL BRKT ASSY 92 P7946092 CLAMP BOLT M12-1.75 X 50
11 P7946011 LEVER BOLT M10-1.5 X 30 93-1 P7946093-1 HEX BOLT M8-1.25 X 125
13 P7946013 HORIZONTAL COLUMN BRACKET 96 P7946096 HEX BOLT 5/8-13 X 1-1/2
70 P7946070 AXLE 97 P7945097 WING NUT 8MM
71 P7946071 WORM PINION 123 P7946123 SPECIAL WRENCH
72 P7946072 LIFT HANDLE 127 PN01M HEX NUT M6-1
72-1 P7946072-1 CRANK HANDLE 128 P7946128 LOCATING PIN
73 PSS01M SET SCREW M6-1 X 10 129 PW08M FLAT WASHER 16MM
G7946 Parts List
