Visual Quickstart Guide
320 320
STEP 1: SUPPLY POWER TO THE iKEY
Remove the aluminum cover and install batteries according to
the printed diagram on the battery tray. Alternatively, you may
use the supplied 9VDC power adapter. If you choose to use
rechargeable batteries, connecting the power adapter will
charge the batteries when the power switch is ON. IF YOU
CHOOSE TO USE ALKALINE OR OTHER NON-RECHARGE-
ABLES, DO NOT CONNECT THE POWER ADAPTER AT THE
SAME TIME AS YOU WILL RISK EXPLODING THE BATTER-
IES AND DAMAGING THE iKEYPLUS!!!
STEP 2: CONNECT AUDIO SOURCE
If you are recording from a line-level device (CD player, mixer,
karaoke machine, guitar amp, etc) OR a phonograph turntable,
you must connect it to the RCA inputs as illustrated. If you are
recording using a microphone, it must be connected to the
small 1/8” (3.5mm) jack. More detailed connection instructions
can be found in the connection diagrams before this section.
