6.1 System Level Configuration
This section describes system-wide configuration requirements for each GXV-3000 /
GXP-2000 / BT-200 to work with BroadWorks. Subscriber-specific settings are described
in the next section.
Step Command Purpose
System Configuration Items
Step 1 Set SIP Proxy/Domain.
SIP Server = as.broadworks.net
Set the GXV-3000 / GXP-2000 /
BT-200 SIP server to the Fully
Qualified Domain Name (FQDN)
for the BroadWorks Application
Server cluster.
The domain must match the
domain configured for the
BroadWorks subscriber’s
line/port domain.
Step 2 Set Outbound Proxy.
OutBound Proxy =
alg.broadworks.net
Set the outbound proxy to the
session border controller (SBC)
if one is deployed between the
GXV-3000 / GXP-2000 / BT-200
and BroadWorks.
If there are redundant SBCs, set
it to the FQDN for the SBC
cluster.
Step 3 Enable DNS SRV lookup.
Use DNS SRV = “Yes”
Enable DNS SRV lookups.
Step 4 Set register mode.
SIP Registration = “Yes”
Enable SIP register.
Step 5 Set SIP Timers.
Register Expiration = 60
The default registration period is
60 minutes.
Step 6 Enable reliable response.
Enable 100rel = "Yes"
Reliable provisional response
(PRACK) should be enabled.
Step 7 Enable negotiated DTMF type.
Send DTMF = “via RTP (RFC2833)”
Set the GXV-3000 / GXP-2000 /
BT-200 to enable inband or RFC
2833 negotiated DTMF.
Step 8 Enable BroadSoft mode.
Special Feature = “Broadsoft”
Set the GXV-3000 / GXP-2000 /
BT-200 in BroadSoft mode.
