6 Configuration
Grandstream GXV-3000 / GXP-2000 / BT-200 can be configured via Web GUI Interface
as well as via Configuration File through TFTP or HTTP.
The GXV-3000 / GXP-2000 / BT-200 accepts configuration files in a proprietary binary
format which is produced by the Grandstream configuration tool. The configuration tool
creates a device configuration file based on a configuration template and the device’s
MAC address. All Grandstream products’ sample configuration templates are available on
Grandstream’s web site
. A configuration template file contains all configuration
parameters available for a product, with comments describing allowed values of the
parameters. For a detailed parameter list, please refer to the corresponding firmware
release configuration template
[2] .
When Grandstream device boots up or reboots, it will issue request for a binary
configuration file named “cfgxxxxxxxxxxxx”, where “xxxxxxxxxxxx” is the MAC address of
the device, i.e., “cfg000b820102ab”. The configuration file name should be in lower cases.
Grandstream offers free Configuration File generator software in both Linux/Unix and
Windows platform. Both Configuration File Generators can be downloaded from
Grandstream official web site at
http://www.grandstream.com/DOWNLOAD/Configuration_Tool/ [2] .
The following examples describe how to set the parameters using a configuration file.
The GXV-3000 / GXP-2000 / BT-200 should be configured to load the configuration file
each time it resets or re-synchronizes. For detailed information on automated
provisioning, please check the GXV-3000 / GXP-2000 / BT-200 User Manual
[1] and the
Grandstream configuration tool user guide [2] .
The capabilities of the GXV-3000 / GXP-2000 / BT-200 have been verified for use with
BroadWorks based on the settings described in the following table. For more information
on the meaning, purpose, and applicability of the individual configuration items, see the
GXV-3000 / GXP-2000 / BT-200 configuration template
[2] .
Configuration Files
Files Provided by Partner Level Description
GXV-3000 / GXP-2000 / BT-200
Configuration Template
Example: gxv3000_config_1.0.0.41.txt
gxp2000_config_1.1.2.25.txt
System and
Subscriber Contains configurable parameters that
apply to an individual device in a
deployment.
cfgMAC
Example: cfg000b82000000
System and
Subscriber Binary configuration file generated
from configuration template and an
individual device’s MAC address
