25
APPENDIX A BLOWER PERFORMANCE DATA
BELT DRIVE - STANDARD DOWN SHOT
CPG090 STANDARD BELT DRIVE DOWN SHOT
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.1 3522 750 1.14 3228 706 0.94 2964 661 0.73
0.3 3337 800 1.19 3102 756 1 2800 706 0.76 2504 661 0.59
0.5 3387 844 1.32 2834 806 0.99 2603 757 0.8
0.7 3453 893 1.5 2903 850 1.12
0.9 2957 899 1.29
CPG102 STANDARD BELT DRIVE DOWN SHOT
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.1 3372 747 1.11 3078 703 0.91 2814 658 0.70
0.3 3187 797 1.16 2952 753 0.97 2650 703 0.73
0.5 3237 841 1.29 2684 803 0.96 2453 754 0.77
0.7 3303 890 1.47 2753 847 1.09
0.9 2807 896 1.26
CPG120 STANDARD BELT DRIVE DOWN SHOT
CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP CFM RPM BHP
0.2 4316 780 1.57 4118 738 1.36 3771 687 1.08 3376 644 0.85
0.4 4282 830 1.76 3928 786 1.4 3595 740 1.13
0.6 4232 874 1.87 3872 830 1.52 3444 786 1.2
0.8 3839 880 1.64 3367 836 1.27
1 3326 885 1.4
1.2
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
TURNS OPEN
ESP, In
H
2
O
4 5 0 1 2 3
ESP, In
H
2
O
TURNS OPEN
0 1 2 3 4 5
CPG150 STANDARD BELT DRIVE DOWN SHOT
ESP (IN
W.C.) CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2 5514 2.92 5604 3.22 5064 2.16 4775 1.81 4514 1.49 4271 1.23
0.4 5279 2.74 5110 2.40 4696 1.94 4447 1.63 4123 1.31
0.6 5185 2.67 4813 2.20 4352 1.74 4039 1.43
0.8 4766 2.37 4526 2.02
1.0 4223 2.01
0 TURNS 1 TURN 2 TURNS 3 TURNS 4 TURNS 5 TURNS
NOTE: High Static airflow requires installation of High Static Kit (HSKT*), or factory-built High Static model. Unit factory shipped at 2.5 turns open.
Tables represent dry coil without filter. To compensate for filter, add 0.08" to measured E.S.P. SCFM correction for wet coil = 4%.
