Grindmaster AM-344-04 - Manual (Page 24)

Page 24 Shuttle Brewers & Airpot/Shuttle Brewers
ITEM DESCRIPTION PART #
Reference Front View Picture:
1 Controller PB Single A530-056 (prior to May 2007) ; A530-059 (after May 2007)
2 Relay, Heater 24vdc A531-072 (prior to May 2007) ; A71450 (after May 2007)
3 Valve, Inlet 24vac A537-189
4 Terminal Block A531-035
5 Spray Head APT400-010
6 Orifice Bypass A518-045
7 Fitting Assy Water Inlet A718-226
8 Switch Momentary ** PBIC only A531-025
Reference Lower Warmer Picture:
20 Faucet Hot Water A537-043
21 Light Warmer A515016
22 Switch Warmer A531-026
23 Heater Warmer 120V 100W A535-018
23 Heater Warmer 220V 100W A535-079 (for E230V models)
Reference Top View Picture:
30 Thermostat, Hi Limit A536-023
31 Contactor 4-Pole** A514005 (for models with 3 heaters)
31 Contactor 2-Pole ** A515027
31 Contactor for 2-Pole E230V models A531-083
31 Contactor for 4-Pole E230V models E531-076
32 Transformer, 120/208/240 100W A554-137
33 Valve, Brew 24VAC PB A537-184
34 Valve, Bypass 24VAC PB A537-183
35 Solenoid, Basket Lock 24vdc A554-135
36 Touchpad PB Series A530-057 (prior to May 2007) ; A530-060 (after May 2007)
37 Board AC-DC Rectifier A530-058 (prior to May 2007 only)
38 Spray Elbow A518-046
39 Tee Barbed 3/8" A61152
40 Hose Overflow A585-016
41 Hose Silicone A512012
42 Elbow Silicone A548-129
Reference Tank Lid Picture:
50 Element Ht 5kW 240V (PB, PBVS) A535-010 (for models with 3 heaters)
50 Element Ht 5kW 240V (PBIC) A535-072 (for models with 3 heaters)
50 Element Htr 6.6kW 240V ** (PB, PBVSA) A535-059
50 Element Htr 6.6kW 240V ** (PBIC) A535-071
50 Element Htr 3.7kW 240V ** (PB, PBVSA) A535-068 (for models with 3 heaters)
50 Element Htr 3.7kW 240V ** (PBIC) A535-073 (for models with 3 heaters)
51 Thermistor A725-097
52 Electrode Assembly A712-018
53 Gasket Tank ** A544-029
Parts List for All Precision Brew Models
Models PB-330, PB-430, PBVSA-330, PBVSA-430, PBIC-330, PBIC-430
** part not shown
