-24-
Model g0563/g0564 (Mfg. since 10/11)
Spindle Sanding
the spindle sander on the Model g0563/g0564
produces a high quality sanding finish on inside
contours.
figure 21. spindle sanding.
Edge & End Sanding
proper use of the oscillating edge sander will
yield excellent sanding results due to the oscillat-
ing movement.
figure 22. typical edge sanding operation.
4. when you have completed your sanding
operation, turn the power switch OFF.
3. when you have completed your sanding
operation, turn the power switch OFF.
If you must feed a workpiece into the sand-
ing belt corner first, feed the trailing cor-
ner first. feeding the leading corner first
could cause the sanding belt to grab the
workpiece and jerk it out of your hands.
to perform an edge or end sanding
operation:
1. start the sander by turning the switch ON.
2. support the workpiece against the back stop,
and slowly feed the workpiece into the mov-
ing belt, as shown in
figure 22.
Do not use the spindle sanding attachment
without the spindle table properly installed
and the correct table insert for the drum in
place. failure to do so could result in seri-
ous personal injury.
to perform spindle sanding operations:
1. Make sure that the appropriate spindle and
table insert have been installed correctly and
both are secured tightly.
2. position the table in the desired location and
turn the power switch ON.
3. while securely holding the workpiece, lightly
press it against the spindle and maintain
consistent pressure against the table as
shown in
figure 21. use extra caution when
sanding end-grain.
