GDS8/GHS8 S
PeciFicationS
GDS8
0403A*B
GDS8
0603A*B
GDS8
0804B*B
GDS8
1005C*B
GHS8
0403A*B
GHS8
0604B*B
GHS8
0805C*B
Heating Capacity
Input¹
40,000
60,000
80,000
100,000
40,000
60,000
80,000
Natural Gas Output¹
32,000
48,000
64,000
80,000
32,000
48,000
64,000
LP Gas Output¹
32,000
48,000
64,000
80,000
32,000
48,000
64,000
AFUE²
80
80
80
80
80
80
80
Available AC @ 0.5” ESP
3
3
4
5
3
4
5
Temperature Rise Range (°F)
25 - 55
30-60
35-65
40 - 70
20 - 50
20 - 50
35 - 65
Circulator Blower
Size (D x W)
10” x 6”
10” x 6”
10” x 8”
10” x 10”
11” x 6”
11” x 8”
11” x 10”
Horsepower @1075 RPM
1/3
1/3
1/2
3/4
1/2
3/4
3/4
Speed
4
4
4
4
4
4
4
Vent Diameter³
4”
4”
4”
4”
4”
4”
4”
No. of Burners
2
3
4
5
2
3
4
Disposable Filter (in²)
580
580
770
960
580
770
960
Electrical Data
Min. Circuit Ampacity⁴
8.5
8.5
10.5
10.5
10.5
13.7
13.7
Max. Overcurrent Device (amps)⁵
15
15
15
15
15
15
15
Ship Weight (lbs)
120
130
153
175
120
130
153
¹ Natural Gas BTU/h. For altitudes above 2,000’, reduce input rating 4% for each 1,000’ above sea level.
² DOE AFUE based upon Isolated Combustion System (ICS)
³ Vent and combustion air diameters may vary depending upon vent length. Refer to the latest editions of the National Fuel Gas Code NFPA 54/ANSI Z223.1
(in the USA) and the Canada National Standard of Canada, CAN/CSA B149.1 and CAN/CSA B142.2 (in Canada).
⁴ Minimum Circuit Ampacity = (1.25 x Circulator Blower Amps) + ID Blower amps. Wire size should be determined in accordance with National Electrical
Codes. Extensive wire runs will require larger wire sizes.
⁵ Maximum Overcurrent Protection Device refers to maximum recommended fuse or circuit breaker size. May use fuses or HACR-type circuit breakers of the
same size as noted.
Notes
• All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.
• Gas Service Connection ½” FPT
• Important: Size fuses and wires properly and make electrical connections in accordance with the National Electrical Code and/or all existing local codes.
