Parts list – Grizzly T21888 User Manual
Page 25
model t21888 (mfg. since 2/10)
-
23
-
parts list
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PT21888001
CRANKCASE
42
PW02M
FLAT WASHER 5MM
2
PT21888002
CRANKSHAFT
43
PT21888043 MOTOR 110V
3
PT21888003
CONNECTING ROD
44
PT21888044 HOT PIPE WARNING LABEL
4
PT21888004
CONNECTING ROD BOLT
45
PT21888045 LUBRICATION LABEL
5
PT21888005
COVER GASKET
46
PT21888046 S CAPACITOR 110M 250V W/STUD
6
PT21888006
CRANKCASE COVER
51
PFB30M
FLANGE BOLT M8-1.25 X 30
7
PT21888007
GASKET
52
PW01M
FLAT WASHER 8MM
8
PT21888008
SIGHT GLASS
53
PS21
PHLP HD SCR 8-32 X 3/4
9
PS02M
PHLP HD SCR M4-.7 X 12
54
PLW04M
LOCK WASHER 8MM
10
PT21888010
THERMAL OVERLOAD 15A
55
PN03M
HEX NUT M8-1.25
11
PLW02M
LOCK WASHER 4MM
56
PT21888056 PRESSURE SWITCH LF10-1H
12
PT21888012
VENTED FILL CAP
58
PT21888058 MANIFOLD
13
PT21888013
WRIST PIN RETAINER
59
PT21888059 PRESSURE RELIEF VALVE 130 PSI
14
PT21888014
WRIST PIN
60
PT21888060 QUICK DISCONNECT 1/4" NPT
15
PT21888015
PISTON
61
PT21888061 AIR REGULATOR
16
PT21888016
WIPER RING
62
PT21888062 PLASTIC PLUG
17
PT21888017
COMPRESSION RING SET
63
PT21888063 AIR PRESSURE GAUGE
18
PT21888018
CYLINDER GASKET
64
PT21888064 FITTING NUT
19
PT21888019
CYLINDER BODY
65
PT21888065 STEEL EXHAUST PIPE
20
PT21888020
DOWEL PIN 2.94 X 6.56MM
66
PT21888066 CHECK VALVE
21
PT21888021
INPUT REED VALVE
67
PT21888067 FITTING NUT
22
PT21888022
VALVE GASKET
68
PT21888068 COPPER UNLOADING PIPE
23
PT21888023
VALVE BODY
69
PT21888069 AXLE
24
PT21888024
OUTPUT REED VALVE
70
PW04M
FLAT WASHER 10MM
25
PT21888025
VALVE STOP
71
PT21888071 WHEEL
26
PW05M
FLAT WASHER 4MM
72
PW04M
FLAT WASHER 10MM
27
PS07M
PHLP HD SCR M4-.7 X 8
73
PN02M
HEX NUT M10-1.5
28
PT21888028
HEAD GASKET
74
PT21888074 DRAIN VALVE
29
PT21888029
CYLINDER HEAD
76
PN03M
HEX NUT M8-1.25
30
PW01M
FLAT WASHER 8MM
77
PW01M
FLAT WASHER 8MM
31
PLW04M
LOCK WASHER 8MM
78
PT21888078 RUBBER FOOT
32
PT21888032
HEX BOLT M8-1.25 X 155 C8.8
79
PW01M
FLAT WASHER 8MM
33
PT21888033
EXHAUST ELBOW VALVE
80
PB26M
HEX BOLT M8-1.25 X 30
34
PT21888034
PLEATED PAPER AIR FILTER
81
PT21888081 TANK 6.34 GALLON
35
PT21888035
MOTOR COVER
82
PT21888082 RUBBER GRIP
36
PT21888036
FLAT WASHER 1/4"
83
PT21888083 POWER CORD 110V
37
PS01
PHLP HD SCR #10-24 X 1/2"
84
PT21888084 MOTOR CORD 110V
38
PR02M
EXT RETAINING RING 14MM
86
PT21888086 RUBBER SEAL
39
PT21888039
FAN
87
PT21888087 COPPER SEAL
40
PT21888040
HEX BOLT M5-.8 X 95
88
PT21888088 MACHINE DATA LABEL
41
PLW01M
LOCK WASHER 5MM
89
PT21888089 AIR DRAIN LABEL
