model h0778/h0779 electric hoist -11 -
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PH0779001 BODY 43 PS12M PHLP HD SCR M3-.5 X 6
2 PSB64M CAP SCREW M10-1.5 X 25 44 PH0779044 FAN COVER
3 PH0779003 MOUNTING BRACKET 45 PH0779045 MOTOR FAN
4 PB01M HEX BOLT M10-1.5 X 30 46 PSS03M SET SCREW M6-1 X 8
5 PTLW08M EXT TOOTH WASHER 10MM 47 PH0779047 TOP HOUSING
6 PH0779006 SPECIAL NUT 48 PR04M EXT RETAINING RING 6MM
7 PH0779007 SPOOL END 49 PH0779049 REMOTE SWITCH CORD
8 PH0779008 WEDGE 50 PH0779050 TERMINAL BLOCK
9 PH0779009 SPOOL FLANGE 51 PH0779051 CLAMP PLATE
10 PH0779010 CABLE STOP 52 PH0779052 TAP SCREW M2.4 X 14
11 PH0779011 UPPER CABLE SLEEVE 53 PHTEK2M TAP SCREW M3.5 X 16
12 PH0779012 CABLE 54 PS38M PHLP HD SCR M4-.7 X 10
13 PH0779013 LOWER CABLE SLEEVE 55 PW05M FLAT WASHER 4MM
14 PH0779014 CABLE LOOP GUIDE 56 PH0779056 STRAIN RELIEF SMALL
15 PH0779015 LIFT HOOK 57 PH0779057 STRAIN RELIEF LARGE
16 PH0779024A HOIST SPOOL 58 PH0779058 GROUNDING SHEET
17 PH0779017 SPOOL WASHER 59 PS07M PHLP HD SCR M4-.7 X 8
18 PK10M KEY 5 X 5 X 12 60 PH0779060 POWER CORD W/PLUG
19 PR18M EXT RETAINING RING 17MM 61 PH0779061 HAIRPIN COTTER PIN 25 X 30
20 P6203 BALL BEARING 6203ZZ 62 PH0779062 CLEVIS PIN 10 X 35
21 PSB45M CAP SCREW M8-1.25 X 45 63 PH0779063 CLAMP CONNECTOR
22 PH0779022 SPACING RACK 64 PH0779064 PULLEY CLAMP
23 PS40M PHLP HD SCR M5-.8 X 16 65 PH0779065 PULLEY WHEEL
24 PH0779024A GEAR BOX 66 PW04M FLAT WASHER 10MM
24A PH0779024A GEAR BOX ASSEMBLY 67 PH0779067 MICROSWITCH SHAFT SEAL
25 PSB24M CAP SCREW M5-.8 X 16 68 PH0779068 MICROSWITCH SHAFT
26 PLW01M LOCK WASHER 5MM 69 PH0779069 BOTTOM HOUSING
27 P6201 BALL BEARING 6201ZZ 70 PH0779052 TAP SCREW M2.4 X 14
28 PH0779024A INTERMEDIATE SHAFT 71 PH0779052 TAP SCREW M2.4 X 14
29 PH0779024A GRADE 1 GEAR 72 PH0779072 MICROSWITCH
30 PH0779024A GRADE 2 GEAR 73 PH0779073 PLUG-IN SHEET
31 PH0779024A GASKET 74 PH0779074 PLUG-IN SHEET SLEEVE
32 PH0779024A FRONT COVER 75 PH0779075 HOUSING COVER
33 P6202 BALL BEARING 6202ZZ 76 PH0779076 UP/DOWN SWITCH
34 PH0779034 ROTOR 77 PH0779077 CONTROL SWITCH FRONT
35 PH0779035 STATOR 78 PH0779078 EXTENSION SPRING
36 PH0779036 CHASSIS 79 PH0779079 LIMIT BRACKET
37 PH0779037 COMPRESSION SPRING 80 PH0779080 CONTROL SWITCH BACK
38 PH0779038 BRAKE HOOP 81 PH0779081 CORD SHEATH
39 PH0779039 MOTOR COVER 82 PHTEK29M TAP SCREW M3.5 X 20
40 PH0779040 SPECIAL HEX BOLT 83 PH0779083 CAPACITOR
41 PW02M FLAT WASHER 5MM 84 PH0779084 SPACER
42 PW07M FLAT WASHER 3MM
h0779 parts list
