model h0778/h0779 electric hoist
-9
-
h0778 parts list
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PH0778001
BODY
43
PW07M
FLAT WASHER 3MM
2
PSB14M
CAP SCREW M8-1.25 X 20
44
PS12M
PHLP HD SCR M3-.5 X 6
3
PH0778003
MOUNTING BRACKET
45
PH0778045
MOTOR FAN COVER
4
PH0778004
HEX BOLT M8-1.25 X 25 G-8.8
46
PH0778046
MOTOR FAN
5
PTLW07M
EXT TOOTH WASHER 8MM
47
PH0778047
CONNECTION CORDS
6
PW01M
FLAT WASHER 8MM
48
PH0778048
TOP CONNECTING HOUSING
7
PH0778007
SPOOL END
49
PH0778049
TERMINAL BLOCK
8
PH0778008
SPOOL WASHER
50
PS59M
PHLP HD SCR M3-.5 X 14
9
PH0778009
SPOOL FLANGE
51
PSB50M
CAP SCREW M5-.8 X 10
10
PH0778010
CABLE
52
PH0778052
TAP SCREW M3.5 X 14
11
PH0778011
CABLE STOP
53
PW05M
FLAT WASHER 4MM
12
PH0778012
CABLE FASTENING SLEEVE
54
PH0778054
CLAMP PLATE
13
PH0778013
CABLE LOOP GUIDE
55
PH0778055
BOTTOM HOUSING
14
PH0778014
LIFT HOOK
56
PS52M
PHLP HD SCR M4-.7 X 20
15
PH0778025A HOIST SPOOL
57
PH0778057
GROUNDING SHEET
16
PK06M
KEY 5 X 5 X 10
58
PTLW01M
EXT TOOTH WASHER 4MM
17
PR05M
EXT RETAINING RING 15MM
59
PS07M
PHLP HD SCR M4-.7 X 8
18
P6202
BALL BEARING 6202ZZ
60
PH0778060
STRAIN RELIEF LARGE
19
PH0778019
SPACING RACK
61
PH0778061
POWER CORD W/PLUG
20
PSB45M
CAP SCREW M8-1.25 X 45
62
PH0778062
MOTOR CORD
21
PRP42M
ROLL PIN 3 X 20
63
PH0778063
PLUG-IN SHEET
22
PH0778025A COMPRESSION SPRING
64
PH0778064
PLUG-IN SHEET SLEEVE
23
PH0778025A DOUBLE ENDED STUD
65
PH0778065
MICROSWITCH BOX
24
PW02M
FLAT WASHER 5MM
66
PR04M
EXT RETAINING RING 6MM
25
PH0778025A GEAR BOX
67
PH0778067
MICROSWITCH SHAFT
25A PH0778025A GEAR BOX ASSEMBLY
68
PH0778068
MICROSWITCH
26
PSB20M
CAP SCREW M5-.8 X 14
69
PH0778069
TAP SCREW M2.4 X 14
27
PLW01M
LOCK WASHER 5MM
70
PH0778070
MICROSWITCH COVER
28
P6200A
BALL BEARING 6200
71
PS34
PHLP HD SCR M3-.5 X 25
29
PH0778025A INTERMEDIATE SHAFT
72
PHTEK28M
TAP SCREW M4 X 25
30
PK06M
KEY 5 X 5 X 10
73
PH0778073
CORD CLIP
31
PH0778025A GRADE 1 GEAR
74
PH0778074
STRAIN RELIEF SMALL
32
PH0778025A GRADE 2 GEAR
75
PH0778075
REMOTE SWITCH CORD
33
PH0778025A GASKET
76
PH0778076
UP/DOWN SWITCH
34
PH0778025A FRONT COVER
77
PH0778077
CONTROL SWITCH FRONT
35
P6202-2RS
BALL BEARING 6202 W/2 RS
78
PH0778078
CONTROL SWITCH BACK
36
PH0778036
ROTOR
79
PH0778079
CORD SHEATH
37
PH0778037
STATOR
80
PC060A
CAPACITOR 60MFD 250VAC
38
PH0778038
CHASSIS
81
PH0778081
HAIRPIN COTTER PIN 25 X 30
39
PH0778039
COMPRESSION SPRING
82
PH0778082
CLEVIS PIN 8 X 30
40
PH0778040
BRAKE HOOP
83
PH0778083
PULLEY HOOK ASSEMBLY
41
PH0778041
GEAR COVER
84
PW04M
FLAT WASHER 10MM
42
PH0778042
HEX BOLT M5-.8 X 140
