-58- G0453/G0454 (Mfg. Since 3/08)
G0454 headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PVMX60 COGGED V-BELT MX-60 48 P0454048 WORM HOUSING
2 PSB26M CAP SCREW M6-1 X 12 48A P0454048A WORM HOUSING ASSEMBLY
3 P0454003 MAG SWITCH ASSEMBLY 49 P0454049 RETURN ROLLER
3-1 P0454003-1 MAG SWITCH COVER 50 PSB01M CAP SCREW M6-1 X 16
3-2 P0454003-2 SWITCH BRACKET 51 P0454051 ROLLER STAND
3-3 P0454003-3 CONTACTOR NHD 35D 220V 52 PFB01M FLANGE BOLT M6-1 X 12
3-4 P0454003-4 OL RELAY NHD BTH-25 26-32A 53 P0454053 DUST HOOD
3-5 P0454003-5 MAG SWITCH BACK 54 P0454054 SPONGE GASKET
4 P0454004 CHAIN 06B-1 X 67 55 PFB01M FLANGE BOLT M6-1 X 12
5 PSB04M CAP SCREW M6-1 X 10 56 P0454056 TOP COVER
6 P0453009 HANDWHEEL LABEL 57 PB107M HEX BOLT M5-.8 X 12
8 P0454008 OIL LEVEL LABEL 58 P0453061 CUT LIMIT PLATE
9 P0453011 COLLAR 59 PSS14M SET SCREW M8-1.25 X 12
10 P0453012 EXTENSION SPRING 60 PEC05M E-CLIP 15MM
11 P0453014 HANGER 61 P0454061 SHAFT
12 P0453015 SHAFT 62 P0453065 COLLAR
13 P0453016 BRACKET 63 P0453066 ANTI-KICKBACK FINGER
14 P0453017 IDLER PULLEY 64 PW03M FLAT WASHER 6MM
15 P0453018 IDLER SHAFT 65 PB02M HEX BOLT M6-1 X 12
17 P0453020 COLLAR 66 P0454066 CHIP DEFLECTOR PLATE
18 PB02M HEX BOLT M6-1 X 12 67 PFB01M FLANGE BOLT M6-1 X 12
19 PW03M FLAT WASHER 6MM 68 P0454068 HOLDDOWN PLATE
20 P0453021 STAR KNOB M8-1.25 69 PN01M HEX NUT M6-1
24 P0453025 BELT COVER 70 PSS25M SET SCREW M6-1 X 20
25 PN03M HEX NUT M8-1.25 71 PSS04M SET SCREW M6-1 X 12
26 PW01M FLAT WASHER 8MM 72 P0454072 ADJUSTING SHAFT
27 P0453027 SPECIAL BOLT 73 PB09M HEX BOLT M8-1.25 X 20
28 P0453028 BELT GUARD 74 PLW04M LOCK WASHER 8MM
29 PFB09M FLANGE BOLT M6-1 X 10 75 P0454075 PRESSURE BAR
30 P0454030 SAFETY HATCH 76 P0454076 BRACKET
32 PSB12M CAP SCREW M8-1.25 X 40 77 PSS11M SET SCREW M6-1 X 16
34 P0454034 CHAIN DRIVE COVER 78 P0454078 SHAFT
35 P0454035 CUT LIMITER POINTER 79 PFB01M FLANGE BOLT M6-1 X 12
36 PS14M PHLP HD SCR M6-1 X 12 80 P0454080 PLATE SPRING
37 PW03M FLAT WASHER 6MM 81 PN01M HEX NUT M6-1
38 P0453038 SCALE 82 PSS25M SET SCREW M6-1 X 20
39 P0453039 HANDLE 83 P0454083 CHIP BREAKER
40 P0453040 HANDWHEEL 84 PN09M HEX NUT M12-1.75
41 PN09M HEX NUT M12-1.75 85 PLW05M LOCK WASHER 12MM
42 PW06M FLAT WASHER 12MM 86 PR03M EXT RETAINING RING 12MM
43 PK48M KEY 4 X 4 X 20 87 P0454087 LOCKING ROD
44 P0453044 WORM GEAR 88 P0454088 SPROCKET
45 P6201 BALL BEARING 6201ZZ 89 P0454089 OUTFEED ROLLER
46 PR29M INT RETAINING RING 32MM 90 PB83M HEX BOLT M6-1 X 16
47 PSB83M CAP SCREW M6-1 X 55 91 PW03M FLAT WASHER 6MM
