Assembly Battery Installation and Tips
Installation
• Locate the battery compartment door on the swing frame.
• Insert a coin into the battery compartment door and pry the
battery compartment door off of the swing frame.
• Insert four “D” (LR20) alkaline batteries as indicated inside
the battery compartment.
• Replace the battery compartment door.
Battery
Compartment
Door
Hint: We recommend using alkaline batteries for longer
battery life.
Battery Tips
• When swinging, sounds or lights slows/dims/stops, it’s time
to change the batteries!
• Do not mix old and new batteries.
• Do not mix different types of batteries: alkaline, standard
(carbon-zinc) or rechargeable (nickel-cadmium).
• Remove the batteries during long periods of non-use.
Always remove exhausted batteries from the toy. Battery
leakage and corrosion can damage this toy. Dispose of
batteries safely.
• Do not dispose of batteries in a fire. The batteries may
explode or leak.
• Never short circuit the battery terminals.
• Non-rechargeable batteries are not to be recharged.
• Only batteries of the same or equivalent type as recom-
mended in the "Battery Installation" instructions are
to be used.
• If removable rechargeable batteries are used, they are only
to be charged under adult supervision.
• Rechargeable batteries are to be removed from the toy
before they are charged.
• If you use a battery charger, it should be examined regularly
for damage to the cord, plug, enclosure and other parts.
Do not use a damaged battery charger until it has been
properly repaired.
1.5V x 4
“D” (LR20)
SHOWN ACTUAL SIZE
• Fit the toy bar plugs into the sockets on the swing tubes.
Hint: If the toybar plugs do not fit into the sockets, turn the
toybar around. Now, fit the plugs into the sockets.
• Insert two 3.5mm x 1.25cm screws through each plug
and into each socket. Tighten the screws with a Phillips
screwdriver. Do not over-tighten.
22
Plug
Toybar
Plug
Socket
Plug
Hub
3.5mm x 1.25cm Screw - 4
Shown Actual Size
