Parts
3
Front Base
Rear Base
Seat with Restraint
2 Seat Tubes
Seat Wire
2 Seat Wire
Caps
2 Accessory Bins
Pad
Toybar
(Toys may be different)
Tray
2 Front Legs
(Longer)
M4 Screw - 4
Shown Actual Size
#8 x 1
1
/
4
" Screw - 6
Shown Actual Size
3.5mm x 1.25 cm Screw - 4
Shown Actual Size
2 Rear Legs
(Shorter)
Bracket
Housing
Motor Housing
