List of features
4 - English
A26361-D1961-Z120-1-7419, edition 2
Internal ports
D1961-A
DIMM Sockets (DDR 400, SDRAM, PC3200)
2
AGP Slot (2/4/8x, 32 bit, 66 MHz, 1.5 V)
1
PCI slot (32 bit, 33 MHz, 3.3 V, Rev. 2.3)
3
CNR Slot (Type A, AC‘97 only)
-
Serial ATA interface (150 Mbyte/s) /
ATA interface (100 Mbyte/s) / Floppy interface
2 / 2 / 1
S/PDIF 5.1 (digital Audio)* OUT / IN
- / -
Audio Input
1
Front panel Audio (9-pin for headphone,
microphone)
1
FireWire
TM
* (9-Pin, Intel standard header)
-
USB Ports* (2.0, ~480 Mbit/s)
4
Serial Ports* (FIFO, 16550 compatible)
-
Fan Connectors PSU** / CPU / AUX1 / AUX2
- / 1 /1 / -
SMBus Connector* (Case Temperature)
-
Cover monitoring* (Casing open)
-
Power supply BTX*** / ATX12V / AGP PRO
1 / 1 / -
External ports
D1761-A
VGA 1
Audio Mic. In / Line in / Line out (or configurable
with driver)
1 / 1 / 1
S/PDIF 5.1 (digital audio, cinch)* OUT / IN
- / -
LAN (RJ-45)
1
PS/2 mouse/keyboard
1 / 1
FireWire™ * (6-Pin, IEEE 1394 port)
-
USB Ports (2.0, ~480 MB/s)
4
Serial Ports (RS232, FIFO, 16550 compatible)
1
Parallel Port (EPP/ECP)
1
*
for use with internal devices or optional Front or Rear panel
**
not supported by standard power supplies
*** BTX (24-pin) compatible to ATX (20-pin)
