Assembly Assembly
Lower Post
Rib
Base
9
Groove
IMPORTANT! Assembly of the lower post to the base is a
permanent assembly.
• Align the rib on the bottom of the lower post with the groove in the
opening in the base.
Hint: For easier assembly, apply a small amount of liquid soap around the
bottom of the post. If assembling indoors, place a tarp under the base to
protect the fl oor surface.
• Insert the lower post into the opening and push down, using a circular
motion, until it snaps into place.
Note: The collar may already be factory assembled.
• Align the lever on the side of the collar with the opening in the top of the
lower post.
• Fit the collar onto the lower post, making sure the peg on each side of the
collar snaps into the hole on each side of the post.
Collar
Lever
Opening
Lower
Post
Hole
Peg
10
• If the lever comes off, simply re-attach it.
• Insert the peg on one side of the lever into the hole in the collar.
• Snap the other peg in the lever into the other hole in the collar.
Assembly is now complete.
Please refer to assembly step 2 to fi ll the base with water or approximately
50 lbs. (22.7 kg) of sand (water and sand not included) to keep this
product stationary.
