Parts
Parts
4
5
6
Collar
Backboard
Ball
Rim
Lower Post
Upper Post
Plug
Base
Note: Label not shown
Hint: Some parts were placed inside the lower post for shipping.
Sound Box
Paddle
BOTH SHOWN ACTUAL SIZE
Note: Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten.
#6 x
3
/
4
" (1.9 cm) Screw - 4
#8 x 2
1
/
4
" (5.7 cm) Screw - 1
