9105/9107 47
9 Digital Communication Interface
Command Description
Command
Format Command
Example
Returned
Returned
Example Acceptable
Values
Display Temperature
Read current set-point s[etpoint] s set: 9999.99 {C or F} set: 150.00 C
Set current set-point to n s[etpoint]=n s=450 Instrument Range
Read scan function sc[an] sc scan: {ON or OFF} scan: ON
Set scan function: sc[an]=on/of[f] ON or OFF
Turn scan function on sc[an]=on sc=on
Turn scan function off sc[an]=of[f] sc-of
Read scan rate sr[ate] sr srat: 999.99 {C or F}/min srat: 10.0 C/min
Set scan rate to n degrees per minute sr[ate]=n sr=5 .1 to 100°C
Read display temperature hold status hm[ode] hm hm: {OFF or AUTO or NO or NC}
Set display temperature hold mode: hm[ode]=OF[F]/AU[TO]/N
O/NC OFF or AUTO or NO
or NC
Set hold mode to off hm[ode]=OF[F] hm=of
Set hold mode to automatic hm[ode]=AU[TO] hm=auto
Set hold mode to normally open hm[ode]=NO hm=no
Set hold mode to normally closed hm[ode]=NC hm=nc
Read temperature t[emperature] t t: 9999.99 {C or F} t: 55.69 C
Read hold status ho[ld] ho ho:{Closed or Open}, 9999.99 {C
or F} ho: Open, 75.0 C
Secondary Menu
Read proportional band setting pr[op-band] pr pb: 999.9 pb: 15.9
Set proportional band to n pr[op-band]=n pr=8.83 Depends on
Configuration
Read cutout setting c[utout] c c: 9999 {C or F} c: 620 C, in
Set cutout setting: c[utout]=n/r[eset]
Set cutout to n degrees c[utout]=n c=500 Temperature Range
Reset cutout now c[utout]=r[eset] c=r
Read heater power
(duty cycle)
po[wer] po p%: 9999 po: 1
Ramp and Soak Menu
Read number of programmable set-points pn pn pn: 9 pn: 2
Set number of programmable set-points to n pn=n pn=4 1 to 8
Read programmable set-point number n psn ps3 psn: 9999.99 {C or F} ps1: 50.00 C
Set programmable set-point number n to n psn=n ps3=50 1 to 8, Instrument
Range
Read program set-point soak time pt pt ti: 999 ti: 5
Set program set-point soak time to n minutes pt=n pt=5 0 to 500
Read program control mode pc pc prog: {OFF or ON} prog: OFF
Set program control mode: pc=g[o]/s[top]/c[ont] GO or STOP or CONT
Start program pc=g[o] pc=g
Stop program pc=s[top] pc=s
Continue program pc=c[ont] pc=c
Read program function pf pf pf: 9 pf: 3
Table 2 Communications Commands
