33
Self Test Results
System test
The system test check results appear at each power on or
whenever the system check is conducted though the self test.
SYSTEM CHECK
---------CI-800---------
IP VOL 66503001** ICP Board ROM prog. no.
IP DSW “00 00” IPU Board’s DIP switch setting
in hexadecimal notation
IP MEM 1 2 3 4 5 6 OK ICP Board memory test
IP MEM 7 8 9
---------CI-810---------
CP VOL 66503101** JCPA Board ROM prog no.
CP VOL 66503110**
CP MEM 1 2 3 4 5 6 7 8 OK JCPA Board memory test
CP DSW “00 00 00 00” JCPA Board’s DIP switch
setting in hexadecimal notation
FT VOL 66503201** JFTA Board ROM prog. no.
FT NEM 1 2 3 4 5 6 7 OK JFTA Board memory test.
TX DEV 1 OK TX device test.
IF VOL 66500401** JIFA Board ROM prog no.
IF MEM 1 2 3 JIFA Board memory test
IF DSW “00 00 00” JIFA Board’s DIP switch setting
in hexadecimal notation
IF DEV 1 JIFA Board device test
IF AN1 RU3 00V RL2.00V OK
AD Converter reference voltage
test
IF AN2 MLD 2.50V Temperature sensor signal test
IF AN3 PWR 1.01V Power check
IF AN4 PTH…RLL…V Inclinometer signal test
IF AN5 IS1 1.01V IS2 1.01V
ERR No. Error Number NOTE: **indicates version no.
Test ICP JCPA JFTA JIFA
Prog. ROM test 5 6 1 1
Data ROM test 6
Memory test 1-4, 7-9 1-5, 7-8 2-7 2-3
