Follett T400A/W - Manual (Page 12)

5.25"
(134mm)
25.875"
(658mm)
icemaker
power outlet
icemaker
twist-lock
bin signal cord
3/8" OD push-in condenser inlet
(water-cooled only)
3/8" OD push-in condenser drain
(water-cooled only)
3/8" OD push-in icemaker water inlet
barbed push-on icemaker drain
vertical utility panel
3/8" OD push-in condenser inlet
(water-cooled only)
3/8" OD push-in condenser drain
(water-cooled only)
3/8" OD push-in icemaker water inlet
icemaker power cord
bin signal cord connector
(to connect to dispenser bin signal cord)
22.75"
(578mm)
25.875"
(658mm)
19.25"
(489mm)
16"
(407mm)
1.563"
(40mm)
Icemaker front
16.75"
(415mm)
22.75"
(578mm)
3/4" MPT icemaker drain
cord holder
1.563"
(40mm)
12
Plan view
Side view
(All customer field
connections are made
to rear of vertical
utility panel)
Front view
