Model X-34 Owner’s Manual
Thank you for purchasing the Fostex Model X-34 multitracker.
The X-34 is a four-track, four-channel cassette tape recorder that features four line inputs, plus two inputs that accept
a range of inputs from line level to mic level. Each channel module is equipped with a two-band EQ for superior sound
quality. The X-34 also provides flexible elements, such as the AUX send/return connectors for applying desired external
effects and the recording track-select switches that enable you to specify any track as the recording destination. A speed
of 9.5cm/s and Dolby B type noise reduction ensure high quality recording. In particular, the exclusive Fostex “Auto
Bounce function” makes ping-pong recording a breeze.
The X-34 contains a “Rehearsal” mode, which is convenient for punching in and out. You can practice until you are
ready to record.
Please read this owner’s manual thoroughly before using the X-34 to make the best use of its features and extend the
useful life of the unit.
Precautions (please read before use)
Power supply
* When unplugging the AC adapter from an outlet, be
sure to grasp the adapter. Attempting to unplug it by
pulling on the AC cable may damage the wiring.
* It is dangerous to use any power cable that is cut or
frayed. If the power cable is damaged, immediately
stop using it and have the unit repaired.
* Do not plug in or unplug the AC adapter with wet
hands. Doing so may result in dangerous electrical
shock.
* Do not open the unit or touch any parts inside.
Doing so may result in a dangerous electrical shock,
and may damage the unit.
* Do not let water or other liquids, flammable
materials, or metal objects such as pins get inside
the unit.
These items may cause electrical shock or short
circuit the X-34 and damage it.
If the X-34 should become wet, unplug the AC adapter
from the AC outlet, and contact your authorized
service station.
* When turning the power on, turn the X-34 on first
before turning on any connected equipment. Doing
so will avoid damaging to the other equipment.
Also, when connecting or disconnecting cables to or
from the X-34’s input or output jacks, set all faders
to “0.”
* When the AC adapter is connected to an AC outlet, it
will continue to draw a small amount of power even
if the switch is set to off (STANDBY).
If you will not be using the X-34 for an extended
period of time, be sure to unplug the AC adapter from
the outlet.
Location
Avoid using the X-34 in the following locations:
* Locations of extreme low or high temperatures, or
subject to extreme changes in temperature.
* Locations with excessive moisture or dust.
* Locations subject to direct sunlight for an extended
period of time, or near a stove or other source of
heat.
* Locations subject to fluctuations in electrical voltage.
* Unstable locations or locations subject to heavy
vibration.
* Near strong magnetic fields (e.g., on top of a television
or speaker).
Table of Contents
Precautions (please read before use) ...................... 3
Cautions for Using the X-34 ....................................... 4
Before Using the X-34 ................................................. 4
Basic Operation: “Let’s Record!” .............................. 9
Initial mode after the X-34 is powered on: ..................... 9
Initial setup of the X-34 ................................................... 9
Remember the following before you start to record! .... 10
Basic Recording - 1 (Recording from the front
panel LINE IN/INSERT jack) ...................................... 12
Basic Recording - 2 (Recording with the rear
panel MIC IN jack) ...................................................... 14
Basic Playback Procedure ............................................. 15
Multitrack Recording ................................................. 16
Overdubbing ................................................................... 16
Mixdown (Track Down mode) ....................................... 18
Advanced Operation ................................................. 19
Punch In/Out Recording ................................................ 19
Ping-pong Recording
(Using the Auto Bounce Function) ................................ 21
Tape Sync ....................................................................... 23
Recording a sync signal ................................................. 24
Applying Effects ............................................................. 25
Troubleshooting ............................................................. 27
Maintenance ................................................................... 28
Block Diagram ............................................................... 28
Specifications ................................................................. 29
Declaration of EC Directive .......................................... 30
The Affect of Immunity on This Equipment ................... 30
FOSTEX DISTRIBUTORS LIST IN EUROPE .............. 30
