4
FTP-622DCL/DSL
No. Signal I/O Contents No. Signal I/O Contents
1 NC — No connection 2 NC — No connection
3 NC — No connection 4 NC — No connection
5 NC — No connection 6 NC — No connection
7 NC — No connection 8 NC — No connection
9 NC — No connection 10 NC — No connection
11 NC — No connection 12 NC — No connection
13 NC — No connection 14 NC — No connection
15 NC — No connection 16 NC — No connection
17 NC — No connection 18 NC — No connection
19 NC — No connection 20 NC — No connection
21 NC — No connection 22 NC — No connection
23 NC — No connection 24 NC — No connection
25 SLCTIN I Select signal 26 INPRM I Reset signal
27 NC — No connection 28 NC — No connection
29 ATF I Paper feed request 30 GND — GND
7. Connector for control signal input/ output (CN1)
Part number : FCN-605Q030-G/S (Fujitsu Components)
Mating connector : FCN-607B030-G/D (Fujitsu Components) or equivalent
*Do not connect outside signal to NC.
