FTP-622DCL/DSL
■
CONNECTOR PIN ASSIGNMENT
1. Connector for power supply (CN10)
Part number
: B6P-VH (J.S.T)
Mating connector part number : VHR-6N (J.S.T) or equivalent
No.
Signal
I/O
Contents
No.
Signal
I/O
Contents
1
V
CC
—
Power supply for logic (+5 V)
2
GND
—
GND (5 V, 24 V common)
3
GND
—
GND (5 V, 24 V common)
4
GND
—
GND (5 V, 24 V common)
5
V
DD
—
Power for head/motor (+24 V)
6
V
DD
—
Power for head/motor (+24 V)
2. Connector for thermal head drive (CN8)
Part number
: B16B-PH-K-S (J.S.T)
Mating connector part number : PHR-16 (J.S.T) or equivalent
No.
Signal
I/O
Contents
No.
Signal
I/O
Contents
1
VDH
O
Power for head (+24 V)
2
VDH
O
Power for head (+24 V)
3
GND (VDH)
—
Head GND
4
GND (VDH)
—
Head GND
5
STB1
O
Print enable signal 1
6
STB2
O
Print enable signal 2
7
STB3
O
Print enable signal 3
8
TMP
I
Temperature detection signal
9
STB4
O
Print enable signal 4
10
LAT
O
Print data latch signal
11
STB5
O
Print enable signal 5
12
5 VH
O
Power for logic (+5 V)
13
HCLK
O
Data transmission clock
14
HD
O
Print data output signal
15
GND (VDH)
—
Head GND
16
VDH
O
Power for head (+24 V)
Notes:
• Symbol “——” means a negative logic signal.
• “I” or “O” means a signal direction from the interface board side.
3. Connector for Sensor (CN3)
Part number
: B5B-PH-K-S (J.S.T)
No.
Signal
I/O
Contents
No.
Signal
I/O
Contents
1
+5 V
—
Power for logic (+5 V)
2
PES
I
Paper end detect signal
3
GND (5 V)
—
Logic GND
4
+5 V
—
Power for logic (+5 V)
5
HUP
I
Head-up detect signal
