2-23
2.11.1 Standard 1 ½” Drain and Oil Return Components Parts List
ITEM PART # COMPONENT
826-1824 Frypot Kit, 2424E (No Front Return)
1 823-3732SP Frypot Assembly, 1824ECF Electric
823-3721SP Frypot Assembly, 2424ECF Electric
2 813-0768 Tee, 1824 Right Drain Flush
3 810-2276 Nipple, UFF Drain Line
4 809-0884 Nut, Slip-Joint
5 816-0544 O-Ring
6 200-1845 Tube, 1⅝-inch X 24½-inch Drain Manifold
7 810-2556 Tube, Front Oil Return
8 813-0868 Plug, 1½-inch NPT Pipe
9 813-0732 Nipple, 1½-inch X 2-inch NPT Toe
10 813-0765 Tee, 1½-inch X 1¼-inch X 1½-inch
11 813-0391 Nipple, 1¼-inch X Close NPT
12 810-2052 Valve, Drain 1¼-inch
13 813-0659 Cap, 1½-inch NPT Pipe
14 813-0143 Nipple, 1¼-inch X 2½-inch NPT Toe
15 813-0760 Tee, 1½-inch X 1¼-inch X 1½-inch NPT Drain
16 813-0686 Cap, Drain Flush End (1824G Left)
17 813-0165 Elbow, ½-inch X 90° NPT Street
18 200-1838 Tube, 1⅝-inch X 17½-inch Drain Manifold
19 813-0632 Elbow, ⅜-inch X 90° NPT Street
20 810-2125 Valve, ⅜-inch Oil Return Ball
* 823-3465 Handle, UFF Oil Return
* 816-0548 Cap, Yellow Vinyl Oil Return Handle
21 813-0614 Fitting, ½-inch X ⅜-inch 37° Flare
22 823-3174 Plug, Frypot Drain
* Not illustrated.
