2

FTP-628MCL401/451

n

ParT NuMbers

Part number

FTP-628MCL40

Printing method

Thermal-line dot method

Dot structure

384 dots/line

Dot pitch (Horizontal)

0.25 mm (8 dots/mm)—Dot density

Dot pitch (Vertical)

0.25 mm (8 dots/mm)—Line feed pitch

Effective printing area

48 mm

Number of columns

ANK 32 columns/line (maximum 2 x 24 dot font)

Paper width

58 mm

Paper thickness

60 to 00 µ m (some paper in this range may not be used because

of paper characteristics)

Printing Speed

Maximum 60mm/sec. (480 dot line/sec.) at 8.5V

Alphanumeric, kana:

59 types

International characters:

95 types

JIS Kanji (Kanji CG loaded board):

about 6800 types

2 × 24 dots, (.5 × 3.0 mm), 32 columns: ANK

24 × 24 dots, (3.0 × 3.0 mm), 6 columns: ANK

8 × 6 dots, (.0 × 2.0 mm), 48 columns: ANK

6 × 6 dots, (2.0 × 2.0 mm), 24 columns: ANK

n

sPeCiFiCaTiONs

Specifications

Item

Character types

Character, dimensions (W×H), number
of columns

Name

Part Number

Printer mechanism with cutter

FTP-628MCL40 (Easy Load Model)

Printer mechanism without cutter

FTP-628MCL45 (Easy Load Model with platen bracket + lock

lever)

LSI for driving

FTP-629CU45R

Interface board for

Mechanism/Cutter

Cutter supported

FTP-628DSL49R Parallel (Centronics) / Serial (RS-232C)

Interface cable

Parallel (Centronics) FTP-628Y202
Serial (RS-232C)

FTP-628Y302

Power cables

Head, motor, logic

FTP-628Y402
