SPECIFICATIONS
Note
• The specifications and design of this product are subject to change without notice.
General
VCR video heads Four heads
Power requirements 120V AC, 60Hz
Power consumption 30W (standby: 3.3W)
Dimensions (width x height x depth) 17.2 x 4.0 x 10.3 inches (435 x 99.5 x 260mm)
Weight 9.5 lbs. ( 4.3kg )
Operating temperature 41°F (5°C) to 104°F (40°C)
Operating humidity Less than 80% (no condensation)
TV system ATSC / NTSC-M TV standard
Recording
Recording format +VR (video recording) format
Recording discs
DVD+Rewritable, DVD+Recordable
DVD-Rewritable, DVD-Recordable (+VR mode only)
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital
Tuner
Tuning system Channel frequency synthesized tuning system
Channel coverage (ATSC / NTSC)
Terrestrial
CATV
VHF 2~13, UHF 14~69
2~13, A~W, W+1~W+94 (analog W+1~W+84), A-5~A1, 5A
Terminals
Front
Audio input
RCA jack x 2
2V rms (input impedance: more than 22kΩ)
Video input
RCA jack x 1
1Vp-p (75Ω)
S-video input
Mini DIN 4-pin x 1
Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)
Rear
VHF/UHF/CATV input and output
F-type
75Ω unbalanced
Audio input
RCA jack x 2
2V rms (input impedance: more than 22kΩ)
Audio output
RCA jack x 4
2V rms (output impedance: more than 1kΩ)
Video input
RCA jack x 1
1Vp-p (75Ω)
Video output
RCA jack x 1
1Vp-p (75Ω)
S-video input
Mini DIN 4-pin x 1
Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)
S-video output
Mini DIN 4-pin x 1
Y: 1Vp-p (75Ω) C: 286mVp-p (75Ω)
Component video out
RCA jack x 3
Y: 1Vp-p (75Ω) P B /C B : 700mVp-p (75Ω) P R /C R : 700mVp-p (75Ω)
Coaxial digital audio out
RCA jack x 1
500mVp-p (75Ω)
HDMI output
HDMI jack x 1
