ASSEMBLY ASSEMBLY
BACK VIEW BACK VIEW
Small Hole
Plug
Crimped
End
STEP 47
• Fit a plug into the crimped end of a support tube.
• Fit a support tube into the small hole in a base. Push the support tube down to snap
into place. Make sure the support tube is fitted to the inside of the upright tube.
• Fit an M6 x 35 mm bolt through the outside of the upright tube and tighten.
Tip: Each plug (inside the support tube) includes an M6 lock nut.
• Repeat this procedure to assemble the other plug and support tube to the assembly.
M6 x 35 mm
Bolt
Support Tube
