Net Tube 3A
Net Tube 2A
M5 x 29 mm Bolt
M5 Lock Nut
STEP 24
• Insert net tube 3A into net tube 2A.
• Fit an M5 lock nut, rounded side out, to the hex
hole in net tube 2A.
• Insert an M5 x 29mm bolt through the opposite
side of net tube 2A. While holding the lock nut in
place, tighten the bolt.
• Repeat steps 23 and 24 to assemble the remaining
net tubes 1B, 2B and 3B.
Rounded
Side
