Specifications
2-2 C141-E198
2.1.2 Function specifications
Table 2.2 shows the function specifications of the IDD.
Table 2.2 Function specifications
Specification
Item
MAS3735FC MAS3367FC
Formatted capacity/device (*1) 73.49 GB (*6) 36.77 GB (*6)
Number of disks 4 2
Number of heads 8 4
Number of cylinders (*2) 27,094 27,150
Formatted capacity/track (B) 285,696 to 360,960
Number of rotations min -1 (rpm) 15,000 ± 0.2%
Average latency time 2.00 msec
Track to Track 0.3 ms/0.5 ms
Average 3.3 ms/3.8 ms
Seek time (*3)
(Read/Write)
Full stroke 8.0 ms/9.0 ms
Start/stop time
(*4) Start time
Stop time
30 s typ. (60 s max.)
30 s typ.
Recording mode 32/34 MEEPRML
External
dimensions
Height:
Width:
Depth:
25.4 mm
101.6 mm
146.0 mm
Weight (max) 0.80kg
Power consumption (*5) 13.0 W 10.2 W
Interface Cable length: 30 m max
Disk drive 93.11 to 118.22 MB/s Data
transfer
rate
FC-AL 212.5 MB/s max.
Logical data block length 512 to 528 byte (Fixed length)
Command specification
FC-PLDA (NCITS TR-19),
FC-PH (ANSI X3.230-1994), FC-PH-2 (ANSI X3.297-1996),
FC-AL (ANSI X3.272-199X), SCSI-FCP (ANSI X3.269-199X)
Data buffer 32 MB FIFO ring buffer (*7)
Acostic noise (Ready) 3.6 Bels typ. (4.1 Bels max.)
(*1) The formatted capacity can be changed by changing the logical block length and using spare sector
space. See Chapter 3 for the further information. The formatted capacity listed in the table is an
estimate for 512 bytes per sector.
(*2) The number of user cylinders indicates the max., and includes the alternate cylinder. The number of
user cylinders and alternate cylinders can be specified at format of the IDD.
(*3) The positioning time is as follows:
