1. OPERATION
4
1.4.1 Display description
Depth category
Speed category
Display title Indication Function
Current depth DPTH Current depth, in meters, feet or fathoms.
Shallow alarm SHALLOW Set shallow depth alarm. Audio and visual
alarms are released when the depth is
lower than the threshold value.
Deep alarm DEEP Set deep depth alarm. Audio and visual
alarms are released when the depth is
higher than the threshold value.
Shallow anchor
alarm SHALLOW Set shallow anchor alarm. Audio and visual
alarms are released when the depth is
lower than the threshold value.
Deep anchor
alarm DEEP Set deep anchor alarm. Audio and visual
alarms are released when the depth is
higher than the threshold value.
Display title Indication Function
Boat speed SPD Boat speed, in knots (kt), miles per hour
(MPH) or kilometers per hour (KMH).
Maximum STW SPD MAX Maximum boat speed, in knots (kt), miles
per hour (MPH) or kilometers per hour
(KMH).
Average STW SPG AVG Average boat speed, in knots (kt), miles per
hour (MPH) or kilometers per hour (KMH).
SOG SOG Speed over ground, in knots (kt), miles per
hour (MPH) or kilometers per hour (KMH).
Maximum SOG SOG MAX Maximum speed over ground, in knots (kt),
miles per hour (MPH) or kilometers per
hour (KMH).
Average SOG SOG AVG Average speed over ground, in knots (kt),
miles per hour (MPH) or kilometers per
hour (KMH).
VMG to windward VMG Velocity made good to windward, in knots
(kt), miles per hour (MPH) or kilometers per
hour (KMH).
Log LOG Log distance (total distance run), in nautical
miles, (NM) kilometers (KM) or statute
miles (SM).
Trip TRIP Trip distance (distance run between two
points), in nautical miles (NM), kilometers
(KM) or statute miles (SM).
