3. MAINTENANCE & TROUBLESHOOTING
3-3
Thermal paper (NX-700A only)
When the thermal paper runs out completely, the message “Printer error” (center
of screen) and the
X icon (at the right-hand top corner) appear. Replace the
paper as follows.
Name Type Code
No.
Thermal paper TP058-30CL 000-154-047
1. Turn off the power.
2. Press the button shown below to open the paper holder cover.
Eject button
3. Peel the tape from the end of new paper.
Tape
4. Set the new paper in the paper container in the direction shown below.
Paper holder
Paper holder cover
New paper
5. Pull the end of the paper by 2 to 3 cm (as shown above), and then close the
cover.
