2-1
2. OPERATION
2.1 Operating Controls
ENT MENU
ESC
DIM
LIST
PRINT
Turns the power on/off.
Opens the PRINT options.
Opens the LIST options.
Opens menu/Returns to the previous display.
Cursor pad
-Shifts the cursor and display.
-Selects items on menus.
Adjusts the panel and LCD dimmer.
+: Raises the dimmer.
- : Decreases the dimmer.
Registers items on menus.
Display unit, front view
2.2 Turning the Unit On/Off
Press the key to turn the unit on. A beep sounds and the equipment shows
the start up display, where the ROM and RAM are checked for proper operation
and the program no. is displayed. The results of the check are shown as OK or
NG (No Good).
When the results are OK, the list display is shown after five seconds after
completion of the check, with frequency last used before turning the power off.
XX: Program version No.
ROM : OK RAM : OK
Program No.
0850196-XX
FURUNO ELECTRIC CO., LTD.
DUAL CHANNEL NAVTEX
NX-700
