YFPRE18E ELECTRIC FRYER
CHAPTER 4: BUILT-IN FILTRATION
4-2
4. 1 General
Frymaster YFPRE18E fryers come equipped with a built-in filtration system. Photos used in the
procedure illustrations may differ slightly from the filter unit that came with the frying system. The
following procedures apply to all YFPRE18E fryers equipped with built-in filter systems.
4.2 Filtration Preparation
On initial installation and before each use, remove all loose parts from the filter, wash the filter pan
and all accessories in hot, soapy water and dry thoroughly.
4.2.1 Assembling the Filter
The YFPRE18E filter system uses a filter pad
held in place by a hold-down ring to filter
impurities and debris from the cooking oil.
The filter pan is assembled with the following
components (see illustration):
1. Filter pan.
2. Filter support grid.
3. Filter pad
4. Hold-down ring.
5. Crumb screen.
5
4
2
1
3
