AN706-00040-2v0-E
78
7.2.7.2 AAC
In the case of AAC, the simple AV system consists of the four states shown in Figure 55.
④Audio data
playback state
③Audio data
playback stop
state
②Initialization
state
①Reset state
[Initial setting complete]
[Media recognized]
[Play/stop switch press]
[USB memory removed]
[USB memory removed]
[Play/stop switch press] or
[AAC file play finish]
Figure 55 State Transition (AAC)
① Reset State
The simple AV system is in reset state immediately after the power has been
turned on.
In the reset state, internal initialization is executed.
