5.4.2 Driver Related Map Descriptor Parameters

Column Title

Function

Legal Values

Node_Name

Name of Node

One of the node names specified in Section
5.3

CNT_Data_Type Data Type of local buffer

Byte, Word, Dword, Bool

Address

Byte offset into local buffer

RDBC: 0 – 449
WRBC: 4 – 453

Length

Number of CNT_Data_Type items in local
buffer

Byte: 1 – 450
Word: 1 – 225
Dword: 1 – 112
Bool: 1 – 3600
